Dublin, Jan. 09, 2025 (GLOBE NEWSWIRE) -- The "Automotive Millimeter-wave (MMW) Radar Industry Report, 2024" report has been added to ResearchAndMarkets.com's offering.
The pace of mass-producing 4D imaging radars quickens, and the rise of domestic suppliers speeds up.
At present, high-level intelligent driving systems represented by urban NOA are facing more complex driving environments and roads. This poses higher capability requirements for the perception system, requiring it to provide a longer detection range, a wider detection angle, and a higher accuracy. Wherein, radars, as a part of the perception system, can deliver stable performance in rain, snow, fog and low-light environments, especially high-performance 4D imaging radar which can enhance the overall perception capability of the autonomous driving system.
Compared with 3D radar, 4D radar (distance, speed, horizontal azimuth, vertical height) provides point cloud functions by increasing the number of transmitting and receiving channels. From 3T4R (12 channels) to 6T8R (48 channels), and to 12T16R (192 channels) and even to 48T48R (2,304 channels), it offers increasingly high accuracy of point cloud imaging, gradually replacing traditional radars. In the case of multi-radar networking, it can partially replace LiDAR.
With the rising installations and installation rate of ADAS, the installations and installation rate of radars in passenger cars in China ramp up. According to the data from the publisher, in 2023 radars were installed in 10.933 million passenger cars in China, with an installation rate of 52.0%; from January to July 2024, 6.531 million cars were installed with radars, with the installation rate up to 57.3%. At present, there are many players in the automotive radar market, especially more new domestic entrants intensifying the industry competition.
China's radar market is valued at over RMB6 billion in 2024, and domestic radar suppliers begin to grab higher market share.
Combining the industry average price of front/corner radars and the installations of radars, the publisher's data shows that China's passenger car radar market was worth RMB5.82 billion in 2023, up by 13.0% year on year; from January to July 202 the market was valued at RMB3.01 billion, increasing by a small margin of 3.4% on a like-on-like basis. It is expected that the market size will exceed RMB6 billion in 2024.
In terms of product type, front radars boast high value and the largest installations, sweeping about 60% of the overall market; rear corner radars follow, with a market size of RMB1 billion from January to July 2024, or more than 30% of the overall market; front corner radars make up about 7% of the overall market; rear radars are seldom used, taking a lower than 1% share.
Moreover, by installations, Bosch, Continental, and Denso are the top three front radar suppliers in China, with a combined market share of more than 70%. However, under the impact of domestic suppliers, they have seen a declining share year by year (the share of the TOP3: 84.1% in 2022, 82.1% in 2023, and 74.6% from January to July 2024); while the share of domestic suppliers such as Sensortech, Cheng Tech and Huawei is expanding. From January to July 2024, the market share of the three companies totaled 13.3%.
In the context of cost reduction and efficiency improvement and fierce competition, ever more OEMs have begun to choose diverse suppliers that can provide cost-effective radars. As technology advances and the mass production and application of products accelerate, domestic radar suppliers have begun to enter the supply chain systems of more OEMs in the fields of front radars (including 4D radar) and corner radars (including 4D radar), scrambling for bigger market share in the segments.
Development trends of radar technology
At present, the upstream end of the automotive radar industry chain is still dominated by foreign chip/chip module vendors. The main players include Infineon, ADI, NXP, ST, TI, Renesas, onsemi, Arbe and Uhnder. Yet domestic radar suppliers are also developing rapidly, and quite a few start-ups have emerged. Domestic players are led by Calterah, Osemitech, and SenardMicro.
The evolution of radar technology, especially the development of satellite architecture, helps create more cost-effective 4D radar products.
In radar design, the first thing to consider is how to improve antenna efficiency. At present, the industry is developing from microstrip antenna to waveguide antenna technology. For waveguide antennas have low energy loss, suppliers like Bosch and Continental use it. Air waveguide antennas have even lower capacity loss. Suppliers working to promote it include Aptiv (4D radar FLR4+), and XretinAl Technology (compared with microstrip antennas of the same size, its Quasi-Air Integrated Waveguide (AIW) antennas enable a gain boost of about 5dB).
Secondly, the antenna packaging technology is evolving from AoB to AiP (Antenna in Package), to reduce antenna feeder loss. A few companies such as Calterah have launched ROP (Radiator-on-Package) technology, which uses solder balls to connect RF signals, has higher channel isolation, and offers a longer detection range and a wider FOV. The more advanced packaging technology LoP is being used by Continental in the production of its sixth-generation radar chips. LoP (Launch on Package) enables the electromagnetic waves emitted by the radar to propagate directly from the chip through the air waveguide, avoiding the higher energy loss and high cost caused by etching the antenna on the circuit board, achieving low cost and also improving the radar's detection performance.
Signal anti-interference is also a factor that must be taken into account. For example, one of the unique benefits of Uhnder's single 4D digital imaging radar chip with 192 virtual channels (12T 8 x 2R) is the use of advanced digital code modulation (DCM) technology, which can effectively improve the anti-interference performance of the radar system and resist interference signals in various complex environments. In addition, to prevent multiple vehicle radars from transmitting RF signals at the same time in overlapping frequency bands, Continental adopts the intelligent time synchronization approach to prevent interference between the vehicle radars. Moreover to avoid interference from radars on other vehicles when the vehicle is traveling, Code is added to the waveform and Decoding is performed as the echo signal is received. This encryption method is used to shield the interference from other vehicle radars.
In radar design, the most critical thing is that the signal processing architecture is developing towards satellite architecture. This distributed architecture can leave most of the signal processing and object recognition tasks to the central processing unit, thereby exploiting the computing power and computing resources of the central processing unit. The higher computing power and more software processing are a solution to stable detection and other problems of radars in the case of a complex scenario and multiple objects.
Key Topics Covered:
1 Overview of Automotive Radar
1.1 Comparison of Automotive Radar Capabilities
1.2 Working Mechanism of Automotive Radar
1.3 Composition of Automotive Radar
1.4 Classification of Automotive Radars
1.5 Automotive Radar Technology
1.5.1 Summary of Waveguide Antenna Technology and Cases of Its Impacts on Functions
1.5.2 Waveguide Antenna Technology and Cases of Its Impacts on Functions
1.5.3 AiP Technology Creates Ultra-short-range Application Scenarios for Radars
1.5.4 AiP Technology Application Scenario Cases
1.5.5 Iteration of Radar Packaging Technology
1.6 Automotive Radar Industry Chain
2 Application of Automotive Radar
2.1 In-cabin
2.2 Out-cabin
2.3 4D Radar Application Scenarios
2.4 Comparison of Main 4D Radar Suppliers and Solutions
2.5 Comparison of Main 4D Radar-equipped Vehicle Models
2.6 Main Chinese and Foreign Automotive 4D Radar Products Map
3 Automotive Radar Market Trends
3.1 Overall Installations and Installation Rate
3.2 Radar Installations and Installation Rate of OEMs by Type
3.3 TOP 20 Brands by Radar Installations
3.4 TOP 20 Vehicle Models by Radar Installations
3.5 Radar Installation Location Schemes
3.6 Installation of Radars by Price Range of Vehicle Models
3.7 Installations and Installation Rate of Radars in Vehicles by Autonomous Driving Level
3.8 Radar Market Size
4 Foreign Passenger Car Radar Companies
4.1 Bosch
4.2 Continental
4.3 Denso
4.4 Aptiv
4.5 ZF
4.6 Magna
4.7 Valeo
4.8 Hyundai Mobis
4.9 FORVIA Hella
5 Chinese Passenger Car Radar Companies
5.1 Sensortech
5.2 Cheng Tech
5.3 Fusionride
5.4 sinPro
5.5 Muniu Technology
5.6 Autoroad
5.7 Chuhang Tech
5.8 HASCO
5.9 Hirige
5.10 Jingwei Hirain
5.11 Freetech
5.12 Huawei
5.13 Altos Radar
5.14 Geometrical-PAL
5.15 Nanoradar
5.16 Nova Electronics
5.17 Baolong Automotive
5.18 ANNGIC
5.19 Zongmu Technology
5.20 FinDreams Technology
5.21 JOOSPEED Electronic Technology's 4D Imaging Radar - LR606
6 Automotive Radar Chip Companies
6.1 Typical Company 1: TI
6.2 Typical Company 2: Arbe
6.3 Typical Company 3: Uhnder
6.4 Typical Company 4: Calterah
6.5 Typical Company 5: Zenitai Technology
6.6 Typical Company 6: Hxele Electronics
6.7 Typical Company 7: Microcreative
6.8 Typical Company 8: Andar Technologies
6.9 Typical Company 9: SenardMicro
6.10 Typical Company 10: Osemitech
6.11 Other Companies
6.11.1 AirTouch
6.11.2 Milliverse
6.11.3 Possumic
6.11.4 Maxio Technology
